Model

WS-6040

WS-6090

WS-1390

WS-1325

Laser

CO2 glass sealed laser tube,safety IV

Laser power

80W/100W/150W/180W/300W

Work platform size(mm)

600×400

900×600

1300×900

1300×2500

Engraving speed

≤1000mm/s

Cutting speed

≤500mm/s

Worktable

honey-comb or aluminum knife optional

Precision of positioning

≤±0.025mm

Resolution

4000DPI

Min.Engraving size

English letter:1.0*1.0mm

Interface

USB2.0

Working temperature:

0-45 ℃ degree

Control System

RDCAM DSP Control system

Soft Ware

Laser Cut software PLT,BMP,DXF,DST,TIF format supported

CorelDraw, AutoCAD Software Compatible

Transmission

Belt transmission (Standard)

Or ball screw transmission optional for extra cost

Linear Rail

Taiwan HIWIN linear rail

Motor type

Japan Stepper motor

Water Cooling:

Water chiller CW 3000 (60w 80W laser power) Water chiller CW 5000 (100w/130w laser power)

Water chiller CW 5200(150w or higher laser

The Whole Set

1PCS CO2 laser cutting machine 1PCS Water chiller

1PCS Air compressor 1PCS Exhaust Fan 1PCS USB cable

1PCS Exhaust Smoking Pipe

Recommended spare

parts

Laser tube, Focal lens, Reflection Mirror

Power supply

220V/50hz/1kva 220V/60HZ/1PH 110V/60HZ/1ph optional

Machine

dimension(mm)

1670*920*1250

1600*1100*1150

1900*1360*1150

3370*2245*1420

G.W

300KG

300KG

350KG

950KG

Optional for extra cost

1. Red Dot Pointer

2. Up & Down Worktable

3. Rotary Device to engrave round work pieces

4. Servo motor and ball screw transmission.

5. RF metal sealed laser tube optional.
