Model

WS-H1

Laser Source

MAX laser source

Output Average Power

20W

30W

50W

Wave length

1064nm

Beam Quality(M2)

＜1.6

＜1.8

Consumed power

145W-300W

Control System

8-inch touch screen with Linux system

Marking Area

110*110mm

Max speed of galvo head

7000mm/sec

Repetitive positioning accuracy

0.03mm

Type of source

Q-switch fiber laser source

Frequency

30-60KHZ

50-100KHZ

Pulse width

200ns

Graph support

PLT, AI, BMP, JPG.....

Port

USB port

Battery

216Wh, Support work 8 hours

Support Power

AC 110V-240V, 50/60HZ

Cooling system

Air Cooling

Laser Class

Class 1

Marking Material

Metal, Plastic, Jewelry......

Net weight

7KG

Gross weight

10KG
