Products

Model

LX-B1

Laser Source

DAVI

Laser Output Power

30W

Wave length

10.6um

Power supply

110/220V, 50/60HZ

Beam Quality(M2)

<1.2

Laser source frequency

0-25KHZ

Cooling Mode

Air Cooling

Consumed power

<600W

Max speed of galvo head

7000mm/sec

Beam Expander

Multiple 6X

Scan head

16mm Aperture

F-theta Lens

110mm*110mm/140*140mm/175*175mm

Optional lens

210*210mm/300*300mm

Type of source

CO2 laser source

Software

Ezcad2

Auxiliary

Double red light help find focus

Application

PET bottle, plastic, paper,wood....

Package dimenison

1090mm×380mm×810mm

Net weight

80KG

Gross weight

90KG
